Product Description
The Garrett 934076-5006S G25-700 G-Series II Turbocharger is engineered for high-performance applications requiring fast spool, high efficiency, and reliable power delivery. Featuring Garrett’s advanced G-Series II aerodynamics, this turbocharger delivers improved transient response and increased airflow capacity over previous generations.
Rated for up to 700 horsepower, the G25-700 is ideal for street performance, track builds, and motorsports applications. The 0.92 A/R turbine housing with V-Band inlet and outlet provides optimal exhaust flow while maintaining excellent boost response. The internally wastegated (IWG) configuration simplifies installation and reduces the need for external wastegate setups.
Designed with durability and performance in mind, this turbo features a fully machined compressor wheel, high-temperature materials, and a dual ceramic ball bearing system for reduced friction and enhanced longevity.
Key Features:
- Supports up to 700 horsepower
- G-Series II compressor aerodynamics for improved airflow
- 0.92 A/R turbine housing for balanced spool and top-end power
- V-Band inlet and outlet for easy installation
- Internal wastegate (IWG) configuration
- Dual ceramic ball bearing system
- Fully machined compressor wheel for maximum efficiency
Fitment:
- Universal performance applications
- Compatible with custom turbo setups
- Ideal for gasoline and diesel builds targeting up to 700 HP
- Requires custom fabrication and tuning
FAQ
What horsepower range is this turbo designed for?
The G25-700 supports up to 700 horsepower, making it ideal for high-performance street and race applications.
Does this turbo require an external wastegate?
No, this model features an internal wastegate (IWG), simplifying installation and reducing additional components.
What type of connections does it use?
It uses V-Band inlet and outlet connections for secure, leak-free installation and easy servicing.
Is this a direct bolt-on turbo?
No, this is a universal turbocharger and requires custom fabrication, tuning, and supporting modifications.
Specifications for Garrett 934076-5006S
| Specification | Details |
|---|---|
| Part Number | 934076-5006S |
| Brand | Garrett Motion |
| Series | G-Series II |
| Model | G25-700 |
| Compressor Inducer | 54mm |
| Turbine Housing A/R | 0.92 A/R |
| Turbine Housing Type | V-Band Inlet / V-Band Outlet |
| Wastegate Type | Internal Wastegate (IWG) |
| Bearing System | Dual Ceramic Ball Bearing |
| Horsepower Rating | Up to 700 HP |
| UPC | N/A |
| GTIN | N/A |
| Shipping Weight | Approximately 25 lbs |
| Shipping Dimensions | 14" x 14" x 14" |
| Prop 65 Warning | This product may contain chemicals known to the State of California to cause cancer and reproductive harm. |
