GARRETT 761208-0079 G50 TURBINE HSG KIT 0.96 A/R T6 V-BAND IN/OUT

Product Description

The Garrett 761208-0079 G50 Turbine Housing Kit is engineered for high-performance turbocharger applications requiring maximum exhaust flow and durability. Featuring a 0.96 A/R ratio and T6 flange with V-band inlet and outlet connections, this turbine housing is ideal for high horsepower diesel and gas builds where efficiency and top-end performance are critical.

Designed specifically for Garrett G-Series G50 turbochargers, this turbine housing kit allows for optimized exhaust gas flow, reduced backpressure, and improved turbo response at higher RPM ranges. The robust construction ensures long-lasting performance even under extreme heat and boost conditions.

This kit is perfect for custom turbo setups, racing applications, and high-output street builds looking to extract maximum performance from their turbo system.

Key Features:

• 0.96 A/R turbine housing for high-flow performance
• T6 flange configuration for large-frame turbo setups
• V-band inlet and outlet for secure, leak-free connections
• Designed for Garrett G50 turbochargers
• Improves exhaust flow and reduces backpressure
• Ideal for high horsepower and racing applications

Fitment:

• Garrett G-Series G50 Turbochargers
• Custom high-performance diesel and gasoline applications
• Compatible with T6 exhaust manifold setups

FAQ

What does the 0.96 A/R mean?
The 0.96 A/R ratio provides a balance favoring top-end power and airflow, making it ideal for high horsepower applications with larger engines or higher boost levels.

Is this a direct bolt-on for all setups?
No, this is designed for custom builds using a Garrett G50 turbo and T6 manifold configuration.

What advantage do V-band connections provide?
V-band connections offer a secure seal, easier installation, and improved durability compared to traditional flange connections.

Is this suitable for street use?
Yes, but it is best suited for high-performance street builds or race applications where maximum airflow is required.

Specifications for Garrett 761208-0079
