Product Description
FASS TSF18290F240G TITANIUM SIGNATURE SERIES DIESEL FUEL SYSTEM 290F 240GPH@65PSI FOR 2017–2021 FORD POWERSTROKE 6.7L
The FASS TSF18290F240G Titanium Signature Series delivers a massive 240 GPH at 65 PSI for 2017–2021 Ford F-250/F-350 6.7L Power Stroke trucks. Built for extreme use (900–1200 HP support), it removes air/vapor, water, and particulate to protect injectors and stabilize rail pressure under load. This kit includes the latest XWS/PF filter strategy and whisper-quiet operation.
Fitment
- Vehicle: 2017–2021 Ford F-250/F-350 6.7L Power Stroke (pickup; cab/chassis may require additional mods—see install manual).
- Flow/Pressure: 240 GPH @ 65 PSI.
- Power Support: ~900–1200 HP capable.
- Filters: Uses XWS3002 Extreme Water Separator (pressure side) + PF3001 Particulate Filter (suction side).
What’s Included
- Titanium Signature Series 65 PSI pump assembly (pre-set).
- Mounting bracketry & hardware, electrical harness.
- Fuel line & fittings for model year fitment.
- XWS3002 & PF3001 service filters pre-installed or included.
Cross-Reference & Related FASS Items (CPP Diesel)
- FASS PF3001 Particulate Filter
- FASS XWS3002 Extreme Water Separator
- FASS PF3001XL Extended Length Particulate Filter
- FASS XWS3002XL Extended Length Extreme Water Separator
- FASS TSF18250F220G (220GPH @ 65 PSI) for 2017–2021
- FASS TSF17290F240G (2011–2016 applications)
Installation & Manuals
Download the official instructions here: Titanium Signature Series 250F/220G & 290F/240G Install Manual (PDF) | All FASS Installation Manuals
FAQ
How much power will this system support?With 240 GPH at 65 PSI, this kit is designed for roughly 900–1200 HP builds when properly fueled and tuned.
Which filters do I order for service?
Use PF3001 (suction side) and XWS3002 (pressure side). For extended intervals, pair PF3001XL with XWS3002XL.
Is there a difference between Titanium Signature Series and Signature Series Plus?
Signature Series Plus adds upgraded fittings/lines. This TSF18290F240G is the standard Titanium Signature Series for 2017–2021 6.7L Power Stroke.
Will cab & chassis trucks fit the same?
Some cab/chassis applications require additional modifications—always review the install manual before beginning.
Do I need tuning with this pump?
No tuning is required just to run the pump; ensure return line routing and fuel supply are correct per the manual.
Specifications for Fass TSF18290F240G
| Brand | FASS Fuel Systems |
| Part Number | TSF18290F240G |
| Series | Titanium Signature Series |
| Flow / Pressure | 240 GPH @ 65 PSI |
| Supported Power | ~900–1200 HP (application dependent) |
| Vehicle Fitment | 2017–2021 Ford F-250/F-350 6.7L Power Stroke (pickup) |
| Filter Strategy | XWS3002 (pressure side) + PF3001 (suction side) |
| UPC | 850044106691 |
| GTIN | 850044106691 |
| Shipping Weight | ~33.5–33.8 lb |
| Package Dimensions | ~17.7 x 13.8 x 11.8 in |
| Country of Origin | USA (per vendor listings) |
| Prop 65 | Yes — Cancer & Reproductive Harm |
| Shipping Method | Ground (standard parcel) |
