HAMILTON CAMS
Here at Hamilton Cams, we are dedicated to making sure you have the best components possible for your diesel engine. We offer valve springs, valve retainers, locks, cast and steel camshafts, pushrods and our newly designed cylinder head for the Cummins 6bt. Our hope is that we will exceed your expectations, in performance, and quality and that we will honor God In our Business practices. If you don’t see what you are looking for, feel free to call us anytime.
- Product
- Qty in Cart
- Quantity
- Price
- Subtotal
-
HAMILTON CAMS 12V DUAL VALVE SPRING SET 89-98 CUMMINS 5.9L
HAMILTON CAMS
$599.00There comes a point as rpm, valve lift, spring pressures and valve size increase, that a single spring is no longer up to the task of controlling the valves. This is when it is time to use a dual spring. Our springs are made in the USA. They come with...$599.00 -
HAMILTON CAMS 07-s-001 165# VALVE SPRINGS, 89-98 CUMMINS 5.9L 12V
HAMILTON CAMS
$399.00Seat Pressure 165 lbs, comes with retainers and locks. Optional locks are available for .075″ higher installed height If you are over 30lbs of boost/drive pressure or over 3500rpm with your 12valve, you are experiencing a few negative things...$399.00 -
HAMILTON CAMS 07-sc-002 VALVE SPRING COMPRESSOR TOOL, 98.5-18 5.9L/6.7L 24V
HAMILTON CAMS
$99.00Cummins 99-Present 24 Valve Spring Compressor tool 24 Valve Spring Compressor tool Makes changing out your valve springs while in the engine very easy. Works with both stock springs and aftermarket valve springs. ...$99.00 -
HAMILTON CAMS 07-CC-24V188 CAST CAMSHAFT COMBO 188/220, 98.5-18 CUMMINS 5.9L/6.7L
HAMILTON CAMS
$1,325.00What’s included: 188/220 Camshaft (fits 89-2018 Cummins) Heavy duty pushrods (500-750 hp) 103 Valve Springs Lifters/tappets Information: RPM Range: 1700-4000 Drops EGT 200-300 Increased Mid Range power Duration at .050″ of lift 188...$1,325.00 -
HAMILTON CAMS 07-s-004 | 24 VALVE STEEL TOOL RETAINERS | 98.5-18 CUMMINS 24V 5.9L/6.7L
HAMILTON CAMS
$99.00If you are running over 4,500 rpm and have a cam with large lobe lift, then these retainers are a must. Over 4,500 can only be run with our #110 springs. The Hamilton Cams 07-s-004 24 valve steel tool retainers fit 1998.5-2024 Cummins 24V 5.9L and 6...$99.00 -
HAMILTON CAMS 07-S-110 | COMPETITION VALVE SPRING SET | 98.5-24 CUMMINS 5.9L/6.7L 24V
HAMILTON CAMS
$499.0024 Valve Competition Springs 110LB seat pressure. Good to 6,500 RPM A must when running your engine over 4500rpm -we suggest steel cam and tappets to combat premature cam wear that is possible with cast cams -we do not suggest these springs for daily...$499.00 -
HAMILTON CAMS 07-H-002 LARGE VALVES, 89-98 5.9L CUMMINS 12V
HAMILTON CAMS
$449.0045 degree 1.850″ intake and 45 degree 1.750″ exhaust. When machining valve seat on OEM head to fit these larger valves, make sure you set valve face at .055″ from cylinder head surface.$449.00 -
HAMILTON CAMS 07-cc-24V178 CAST CAMSHAFT COMBO 178/208, 98.5-18 CUMMINS 5.9L/6.7L
HAMILTON CAMS
$1,325.00What’s included: 178/208 Camshaft (fits 89-2018 Cummins) Heavy duty pushrods (500-750 hp) 103 Valve Springs Lifters/tappets Information: RPM Range: Idle-3000 Drops EGT 200-300 Better fuel economy 2-3 MPG+ Increased bottom end power...$1,325.00 -
HAMILTON CAMS 07-c-178/208 CAST CAMSHAFT 178/208, 89-18 CUMMINS 5.9L/6.7L
HAMILTON CAMS
$649.00Information: RPM Range: Idle-3000 Drops EGT 200-300 Better fuel economy 2-3 MPG+ Increased bottom end power Quicker spool up Duration at .050″ of lift 178 Intake, 208 Exhaust Steel Version of the 178/208 Addition Information: ...$649.00 -
HAMILTON CAMS 07-cc-12V188 CAST CAMSHAFT COMBO 188/220, 89-98 CUMMINS 12V 5.9L
HAMILTON CAMS
$1,375.00What’s included: 188/220 Camshaft (fits 89-2018 Cummins) Heavy duty pushrods (500-750 hp) 165 Beehive Valve Springs Retainers and locks Lifters/tappets Information: RPM Range: 1700-4500 Drops EGT 200-300 Increased Mid Range power Duration at ...$1,375.00 -
HAMILTON CAMS 07-C-188/220S STEEL CAMSHAFT 188/220, 89-18 CUMMINS 5.9L/6.7L
HAMILTON CAMS
$699.00STEEL CAMSHAFT 188/220, 89-18 CUMMINS 5.9L/6.7L MUST USE WITH DLC COATED BILLET STEEL TAPPETS$699.00 -
HAMILTON CAMS 07-CC-12V178 CAST CAMSHAFT COMBO 178/208, 89-98 CUMMINS 12V 5.9L
HAMILTON CAMS
$1,375.00What’s included: 178/208 Camshaft (fits 89-2018 Cummins) Heavy duty pushrods (500-750 hp) 165 Valve Springs Retainers and Locks Lifters/tappets Information: RPM Range: Idle-3000 Drops EGT 200-300 Better fuel economy 2-3 MPG+ Increased bottom end...$1,375.00 -
HAMILTON CAMS 07-c-188/220 CAST CAMSHAFT 188/220, 89-18 CUMMINS 5.9L/6.7L
HAMILTON CAMS
$649.00Information: RPM Range: 1700-4000 Drops EGT 200-300 Increased Mid Range power Duration at .050″ of lift 188 Intake, 220 Exhaust This is the Steel Version of our 188/220 Modification Required: For it to be “drop in” on a...$649.00 -
HAMILTON CAMS 07-T-002 DLC COATED BILLET TAPPETS 1.45", 89-18 CUMMINS 5.9L/6.7L
HAMILTON CAMS
$699.001.45″ steel tappets for high rpm engines with 110# or heavier valve springs$699.00 -
HAMILTON CAMS 07-P-002 EXTREME DUTY PUSHRODS, 89-98 5.9L CUMMINS 12V
HAMILTON CAMS
$224.51If you are over 500hp with your 6bt, the cylinder pressures dictate that you step up to our extreme duty pushrods which consist of a 10.5mm .120″ wall. OEM pushrods have a buckling strength of 1780lbs these pushrods have a buckling strength of...$224.51 -
HAMILTON CAMS 07-T-001 1.45" TAPPETS SET, 89-18 CUMMINS 5.9L/6.7L
HAMILTON CAMS
$159.00These tappets work with all 1989-2016 Dodge Cummins engines. At 1.45″ they will not have interference with the Fuel pump eccentric on 12v engines and are much wider than the 1.1″ tappets used in early 12v engines. This means they have more...$159.00 -
HAMILTON CAMS 07-C-001 ZINC ADDITIVE, 89-18 CUMMINS 5.9L/6.7L
HAMILTON CAMS
$15.99With most current diesel oils this additive will put your zinc and phosphorous at approximately 1500-1650ppm which is ideal for flat tappets cams. Use every oil change in competition engines, at least for break-in on daily drivers...$15.99 -
HAMILTON CAMS 07-P-004 EXTREME DUTY PUSHRODS, 98.5-18 5.9L/6.7L CUMMINS 24v
HAMILTON CAMS
$179.00If you are over 500hp, the cylinder pressures acting on the valve can bend your OEM pushrods before the valve opens. This can retard cam timing and reduce valve lift These pushrods are a 3 piece design that features 12mm diameter .120″ wall, which...$179.00 -
HAMILTON CAMS 07-C-188-220 CAST CAM 188/220-109LSA, 89-18 CUMMINS 5.9L/6.7L
HAMILTON CAMS
$649.00188-220 .320″/.320 109LSA 101ICL This is the best cam for 2,000rpm to 4,000rpm performance Engine Model 03 – 07 5.9L, 07.5 – 18 6.7L, 89-98 12V, 98.5 – 02 5.9L Engine Type Competition,...$649.00 -
HAMILTON CAMS 07-C-RETAINER BOLT ON CAM RETAINER (BRONZE), 89-07 CUMMINS 5.9L 12V/24V
HAMILTON CAMS
$89.00Factory replacement for thrust plate retainer$89.00 -
HAMILTON CAMS 07-c-002 BOLT-ON CAM RETAINER, 89-18 5.9/6.7L CUMMINS 12V/24V
HAMILTON CAMS
$39.99For use with mechanically injected engines with helical cut cam gears. The bolt on retainer will ensure that the cam gear is not pushed off of the cam in high rpm, high fuel delivery situations. Use red loc-tite and torque bolt to 44 ft-lbs Common rail...$39.99 -
HAMILTON CAMS 07-S-003 | 103# VALVE SPRINGS | 98.5-24 CUMMINS 5.9L/6.7L
HAMILTON CAMS
$325.00Stock springs have 78-82lbs of pressure seat pressure on average at 1.380″. If you are over 35psi(boost or drive pressure) and 3,800 rpm, stock springs do not fully control the valvetrain. This allows a few negative things to happen. First, valve...$325.00
