Product Description
The Garrett 757707-0022 G45 Turbine Housing Kit is engineered for high-performance turbocharger applications requiring maximum exhaust flow and efficiency. Featuring a 1.44 A/R ratio and V-band inlet and outlet configuration, this turbine housing is designed to support high horsepower builds while maintaining optimal exhaust gas velocity and turbine efficiency.
Built specifically for Garrett G-Series G45 turbochargers, this turbine housing allows for improved spool characteristics and top-end performance in racing and high-boost applications. The V-band inlet and outlet design ensures a secure, leak-free connection while simplifying installation and maintenance.
This housing is ideal for custom turbo setups, motorsports applications, and performance enthusiasts pushing the limits of their build.
Key Features:
- Designed for Garrett G45 turbochargers
- 1.44 A/R for high horsepower and maximum flow
- V-band inlet and V-band outlet configuration
- Improves exhaust flow and turbine efficiency
- Durable construction for extreme performance environments
- Standard rotation configuration
Fitment:
- Garrett G-Series G45 Turbochargers
- Custom turbo builds and fabrication setups
- Universal performance applications (fitment may vary)
FAQ
What does the 1.44 A/R mean?
The 1.44 A/R ratio refers to the area-to-radius ratio of the turbine housing, offering increased exhaust flow for high horsepower applications at the expense of slightly slower spool.
Is this compatible with all G-Series turbos?
No, this turbine housing is specifically designed for Garrett G45 turbochargers.
What are the benefits of a V-band connection?
V-band connections provide a secure, leak-free seal and allow for easier installation and removal compared to traditional flange setups.
Is this good for street use?
While it can be used on the street, the 1.44 A/R is typically best suited for high horsepower or racing applications where top-end performance is prioritized.
Specifications for Garrett 757707-0022
| Specification | Details |
|---|---|
| Part Number | 757707-0022 |
| Brand | Garrett Motion |
| Product Type | Turbine Housing Kit |
| A/R Ratio | 1.44 A/R |
| Inlet Type | V-Band |
| Outlet Type | V-Band |
| Rotation | Standard Rotation |
| UPC | N/A |
| GTIN | N/A |
| Shipping Weight | Approximately 12 lbs |
| Shipping Dimensions | 12" x 12" x 10" |
| Material | High-Temp Cast Iron |
| Prop 65 Warning | This product may contain chemicals known to the State of California to cause cancer and reproductive harm. |
