FASS NDTSPF15180F140G No-Drop Series Plus Fuel System for 2000-2005 Ford Excursion 6.0L & 7.3L Power Stroke (Stock-700HP)
The FASS NDTSPF15180F140G No-Drop Series Plus Fuel System is the ultimate fuel delivery and filtration upgrade for 2000-2005 Ford Excursion models equipped with the 6.0L or 7.3L Power Stroke diesel engine. Designed to support stock through 700 horsepower applications, this complete No-Drop Series Plus kit combines the proven Titanium Signature Series Plus Fuel System with a FASS Fuel Sump Kit, allowing for a simplified installation without removing or modifying the factory fuel tank.
Rated at 140 gallons per hour and preset to deliver approximately 65 PSI, this system removes over 99% of water, filters contaminants down to an absolute 2 microns, and eliminates entrained air and vapor before fuel reaches your injection system. The result is improved fuel lubricity, smoother engine operation, enhanced cold-weather performance, and significantly increased injector and fuel system life.
Featuring ORB fittings, black anodized 6061 aluminum fittings, black fuel hose, and FASS Whisper Technology, the No-Drop Series Plus Fuel System delivers exceptional performance while maintaining a clean, professional installation.
Features
- Complete FASS No-Drop Series Plus Fuel System
- Supports stock to 700 horsepower applications
- 140 GPH fuel flow capacity
- Preset fuel pressure of approximately 65 PSI
- Includes Titanium Signature Series Plus Fuel System
- Includes FASS SK5501 Fuel Sump Kit
- No fuel tank removal required during installation
- 2-micron absolute fuel filtration
- Removes over 99% of water from diesel fuel
- Eliminates entrained air and fuel vapor
- Improves fuel lubricity by at least 10%
- Helps extend injector and injection pump life
- Whisper Technology for quiet operation
- Black anodized 6061 aluminum ORB fittings and black fuel line
- Optional electric fuel heater available for cold climates
Fitment
- 2000 Ford Excursion 7.3L Power Stroke
- 2001 Ford Excursion 7.3L Power Stroke
- 2002 Ford Excursion 7.3L Power Stroke
- 2003 Ford Excursion 7.3L Power Stroke
- 2003 Ford Excursion 6.0L Power Stroke
- 2004 Ford Excursion 6.0L Power Stroke
- 2005 Ford Excursion 6.0L Power Stroke
Note: This fuel system is designed for stock through 700 horsepower applications and includes the FASS No-Drop Fuel Sump Kit for simplified installation.
What's Included
- FASS Titanium Signature Series Plus Fuel System (TSPF15180F140G)
- FASS SK5501 Fuel Sump Kit
- Fuel hose and installation hardware
- Black anodized ORB fittings
- Installation instructions
Specifications
- Manufacturer: FASS Fuel Systems
- Part Number: NDTSPF15180F140G
- Fuel System Series: No-Drop Series Plus
- Pump Series: Titanium Signature Series Plus
- Flow Rating: 140 Gallons Per Hour
- Horsepower Rating: Stock to 700 HP
- Preset Fuel Pressure: Approximately 65 PSI
- Filtration Rating: 2 Micron Absolute
- Water Separation: Removes Over 99% of Water
- Fuel Sump Included: Yes (SK5501)
- Fuel Heater Compatible: Yes
- Whisper Technology: Yes
- Fittings: ORB Black Anodized 6061 Aluminum
- Fuel Line: Black Performance Hose
- Application: Ford Excursion 6.0L & 7.3L Power Stroke
