CRAZY CARLS TURBOS STOCK 2/3 TWIN TURBO KIT W/472 1994-1998 DODGE CUMMINS 5.9L 12V

This is our 2/3 kit for 94-98 12V Dodge Cummins. It makes adding a second compound (twin) turbo easy. You use your stock turbo, and we supply the rest. These kits take the guess work out of selecting the right combo and perform amazing. No more staring at your EGT gauge or smoking out the neighborhood. Get better MPGs from increased efficiency as well. These kits are easy to install and a joy to drive. You do not have to move your AC, batteries, or even the auto heat exchanger! Get tire roasting, load pulling, worry free performance right out of the box!

Exhaust Manifold: 12Vs require an aftermarket 12V manifold. If you do not have one, see options available above. NOTE: Steed Speed Manifolds do not work with an HX35 in this kit.

*head studs and transmission/clutch upgrades are recommended to match available power range.

Includes all parts needed (see list), PLUS a new S472/83/1.10 T6 turbo. This turbo pairs ideally with your stock turbo, and with proper fueling is rated from stock up to 600hp. Great for street or towing.
This kit will come with a new 472 83/1.10 T6 turbo with upgraded internals and covers by Forced Inductions and a 6-month warranty.

Kit includes:
1-piece metal cold pipe,
Intercooler pipe,
Full 5" intake pipe,
4" or 5"* down pipe,
Stainless top and bottom turbo oil feed lines,
Top and bottom turbo oil drain lines,
Billet block or pan drain fitting,
Bottom turbo support bracket,
Top turbo spacer plate,
Quality name-brand large high flow filter,
SS Vband clamps,
SS T-bar clamps,

NOTES:

• SPRING GATE: If you are using an HX35 that is off a newer 99-02 truck with a compressor mounted waste-gate, you will need to order our spring gate controller.
• DOWNPIPE: As you'd expect, 5 inch downpipes are an exact fit. Due to variations in trucks you may need need to modify your firewall slightly.
• EXHAUST MANIFOLD: Kit requires an aftermarket 12V manifold- will not work with stock 12V manifold. Does not work with a Steed Speed manifold in this turbo (HX35) configuration.

***These kits are custom made to order and may take a week or so to ship.*****
