MAHLE 224-3355WR.040 PISTON KITW/RINGS (.040) FOR 1998.5-2002 CUMMINS 5.9L ENGINE

The MAHLE 224-3355WR.040 is a high-quality piston kit designed for the 1998.5–2002 Dodge Ram 2500/3500 trucks equipped with the 5.9L Cummins 24-valve engine. This kit is ideal for engine rebuilds requiring a 0.040" overbore, offering enhanced durability and performance.

 Specifications

• Bore Size: 4.056 inches (102.97 mm)

• Oversize: +0.040 inches

• Material: Aluminum

• Compression Height: 2.818 inches (71.6 mm)

• Piston Pin Diameter: 1.575 inches (40.00 mm)

• Piston Pin Retention: Floating pin

• Head Type: Reentrant bowl

• Recess Depth: 0.740 inches (18.82 mm)

• Recess Volume: 48.03 cc

• Ring Grooves:

  • Top Compression Ring: 3.00 mm

  • Second Compression Ring: 2.40 mm

  • Oil Ring: 4.00 mm

• Ring Type Code: GCL-40UAW

• Skirt Clearance: 0.0047 inches (measured 0.472 inches from the bottom of the skirt)

• Casting Number: 102L55A2

• Maximum Oversize: +0.040 inches (1.00 mm)

• Application: Non-High Output (Non-HO) engines, VIN code 6


Vehicle Fitment

This piston kit is compatible with the following vehicles:

• Dodge Ram 2500/3500 (1998.5–2002) equipped with the 5.9L Cummins 24-valve engine

 Additional Notes

• Sold in Sets: Pistons are sold individually; a quantity of six is required for a complete engine rebuild.

• OE Quality: Manufactured to original equipment specifications, ensuring reliable performance and longevity.

• Installation: Proper installation is crucial; ensure all mating surfaces are clean and free of debris before sealing.

The MAHLE 224-3355WR.040 Piston Kit is engineered specifically for the 1998.5–2002 Dodge Ram 2500 and 3500 trucks, housing the reliable 5.9L Cummins 24-valve engine. With a bore size of 4.056 inches and an oversize of +0.040 inches, this piston kit is designed for engine rebuilds that demand precision and enhanced performance. Crafted from durable aluminum, the kit promises resilience and reliability, catering to drivers who expect the best from their heavy-duty trucks.

Featuring a compression height of 2.818 inches, this piston kit includes critical specifications such as a piston pin diameter of 1.575 inches and floating pin retention. Its unique head type, characterized by a reentrant bowl, significantly contributes to optimizing combustion efficiency. The precision-engineered recess depth of 0.740 inches and a volume of 48.03 cc complete the design for optimal power output.

Attention to detail is evident in the ring grooves, accommodating a top compression ring, a second compression ring, and an oil ring, meticulously designed for perfect sealing under pressure. The MAHLE piston kit adheres to original equipment specifications, ensuring it delivers dependable performance and longevity, crucial for both casual and demanding driving conditions.

Each piston is sold individually, with six required for a full rebuild. Installation requires attention to detail, advising that all mating surfaces should be properly cleaned to ensure a seamless fit. This kit is compatible specifically with non-high output (Non-HO) engines designated by VIN code 6, ensuring that it meets the unique needs of these vehicles. Elevate your engine's performance and reliability with the MAHLE 224-3355WR.040 Piston Kit, an essential upgrade for any Cummins enthusiast.
