Product Description
FLEECE FPE-61-10009-HD 5.9L VP 98.5-02 FREEDOM SERIES CUMMINS CYLINDER HEAD (STREET-HD)
Upgrade your 1998.5-2002 5.9L VP Cummins engine with the FLEECE FPE-61-10009-HD Freedom Series Cylinder Head (Street-HD). This fully remanufactured unit is built to meet or exceed OEM standards, pressure-checked, decked, painted and ready for installation, with no core charge required.
This head is engineered for high-duty use including heavy towing, daily driving, or mild performance up to 700 horsepower. With premium features like 11 screw-in freeze plugs, hardened oversized press-in valve seats, brand-new valve guide liners, and heavy duty 105 lb valve springs, this is a serious upgrade for your VP 5.9L truck.
Key Features:
- Specifically for 1998.5-2002 5.9L VP 24-valve Cummins engines
- Freedom Series “Street-HD” classification — rated up to 700 hp
- 11 screw-in freeze plugs to eliminate coolant leaks under the valve cover
- Hardened, oversized press-in valve seats for improved durability
- Heavy duty Fleece 105 lb valve springs and tool-steel retainers
- New valve guide liners installed, fully assembled and ready to bolt on
- No core charge required — keep your old head if you wish
- 1-Year Limited Parts Warranty included
Fitment
Engine: 5.9 L VP 24-Valve Cummins
Model Years: 1998.5, 1999, 2000, 2001, 2002
Vehicle Applications:
- 1998.5-2002 Dodge Ram 2500 5.9L VP 24V Cummins
- 1998.5-2002 Dodge Ram 3500 5.9L VP 24V Cummins
Note: Head gasket not included; Fleece recommends using Cummins part # 3977063.
Recommended Fleece Cross-Reference / Related Parts
- FLEECE FPE-61-10009 5.9L VP 98.5-02 FREEDOM SERIES CUMMINS CYLINDER HEAD (STREET)
- FLEECE FPE-61-10006 5.9L FREEDOM SERIES CUMMINS CYLINDER HEAD (PERFORMANCE)
- FLEECE FPE-61-10013-HD FREEDOM SERIES 12 VALVE CUMMINS CYLINDER HEAD (STREET-HD)
Why Choose Fleece Freedom Series for Your 5.9L VP?
When you’re working with the 24-valve 5.9L VP engine, you want a cylinder head that can hold up to high mileage, serious duty, and retain reliability under load. Fleece’s Freedom Series heads are built precisely for that: each unit is fully remanufactured in a facility with modern machining and metrology, pressure and leak tested, surfaced, and finished with quality assembly. Features like the screw-in freeze plugs eliminate a common coolant-leak failure point, and the heavy duty valvetrain components restore durability without going full race spec—perfect for tow trucks, daily drivers, or lightly modified builds.
Installation Notes
- Use new head gaskets and head bolts or high-strength head studs (e.g., ARP 12 mm) for best results.
- Valve lash must be checked and set — adjust rocker arm back off before running. Failure to do so can lead to damage.
- Ensure deck surface and block condition are clean and within spec before installation.
- Freight shipping required due to weight and size of this head.
Specifications for FLEECE FPE-61-10009-HD
| Attribute | Value |
|---|---|
| Brand | Fleece Performance Engineering |
| Part Number | FPE-61-10009-HD |
| Engine | 5.9 L VP 24-Valve Cummins (1998.5-2002) |
| Position | Single Head (no side differentiation) |
| UPC | 670875717367 |
| GTIN | 670875717367 |
| Series | Freedom Series – Street-HD |
| Features | 11 screw-in freeze plugs, hardened oversized press-in valve seats, new heavy-duty 105 lb valve springs, tool-steel retainers, new valve guide liners |
| Max HP Rating | Up to ~700 hp |
| Shipping Info | Freight shipping required; heavy duty cylinder head; contact for shipping quote. |
| Cross Reference | Fleece FPE-61-10009 (Street variant), Fleece FPE-61-10006 (Performance variant), Fleece FPE-61-10013-HD (12 Valve head) |
| E-Codes | Not applicable |
| Prop 65 | WARNING: Cancer & Reproductive Harm – www.P65Warnings.ca.gov |
| Warranty | 1 Year Limited Parts Warranty |
FAQ
Is the FPE-61-10009-HD cylinder head a direct replacement for my 1998.5-2002 5.9L VP Cummins stock head?
Yes. The FLEECE FPE-61-10009-HD is built specifically for 1998.5-2002 5.9 L VP 24-valve Cummins engines and is designed to meet or exceed factory specs while offering upgraded components for durability and heavy duty use.
Do I need to pay a core charge when ordering this head?
No. This head comes with no core charge required. You can keep your old head instead of returning it.
What supporting parts should I replace when installing this head?
Fleece recommends using a new head gasket (Cummins part # 3977063), and for any build above stock power levels, using ARP625 or ARP L19 12mm head studs. Proper valve lash must be set and rocker adjusters must be backed off to avoid damage.
What horsepower level is this head rated for?
The Street-HD version of the Freedom Series is rated for up to approximately 700 horsepower in heavy duty use conditions (daily driver, towing).
