Product Description
FASS INDUIM250G INDUSTRIAL SERIES DIESEL FUEL SYSTEM CLASS 8 SEMI 250GPH UIM
The FASS INDUIM250G Industrial Series delivers 250 GPH at a preset 16–18 PSI for Class 8 semi and heavy industrial applications using Unit Injected Mechanical (UIM) fuel systems. It combines FASS’s proven air/vapor separation with 2-micron absolute filtration to protect injectors, improve cold starts, smooth idle, and reduce emissions—backed by a 1 million mile / 5-year warranty.
Fitment & System Notes
- Application: Class 8 / Industrial diesel with UIM (Unit Injected Mechanical) fuel systems.
- Flow / Pressure: 250 GPH @ 16–18 PSI (preset).
- Filtration: 2-micron absolute; removes air/vapor and water to extend injector life.
- Filter pairing: Compatible with the current XWS/PF strategy — XWS3002 Extreme Water Separator (pressure side) and PF3001 Particulate Filter (suction side).
- Mounting: Universal Industrial Mount (UIM) for versatile Class 8 installs.
Installation & Manuals
See the official FASS manuals hub: FASS Installation Manuals and the direct Industrial Series UIM manual: IND-UIM-250G / IND-UIM-290G Installation Manual (PDF).
Cross-Reference & Related FASS Items (CPP Diesel)
- Industrial UIM lineup: INDUIM100G (100GPH), INDUIM165G (165GPH), INDUIM290G (290GPH).
- Industrial Universal (non-UIM) alternative: IND250G (250GPH Universal).
- Filters & packs: XWS3002, PF3001, FP3000 Filter Pack, FP3000XL Filter Pack.
FAQ
What fuel pressure does INDUIM250G run?It’s preset at 16–18 PSI to support UIM industrial applications.
Which filters should I use?
Run the current pair: XWS3002 on the pressure side and PF3001 on the suction side.
Is this system noisy?
No—Industrial Series pumps are engineered for quiet operation while maintaining high flow.
What warranty coverage is included?
FASS backs the Industrial Series with a 1,000,000-mile / 5-year warranty (see manual for terms).
Specifications for Fass INDUIM250G
| Brand | FASS Fuel Systems |
| Part Number | INDUIM250G |
| Series / Mount | Industrial Series / UIM (Universal Industrial Mount) |
| Flow / Pressure | 250 GPH @ 16–18 PSI (preset) |
| Filtration | 2-micron absolute; air/vapor & water separation |
| UPC | 850044106196 |
| GTIN | 0850044106196 |
| Shipping Weight | ~31 lb |
| Package Dimensions | 14.0" W × 11.5" H × 18.0" L |
| Shipping | Free Ground Shipping (Continental U.S.) |
| Prop 65 | Yes — Cancer and Reproductive Harm |
