FASS
FASS COMP330G FUEL SYSTEMS COMP330G COMPETITION SERIES 330GPH (30 PSI MAX)
- SKU:
- FASCOMP330G
- MPN:
- COMP330G
- Shipping:
- Calculated at Checkout
Description
FASS Fuel Systems Competition Series 330GPH (30 PSI MAX). Part No: COMP330G The Competition Series diesel fuel System was specifically designed for high performance diesel applications that demand a large volume of fuel supply.
Each Competition Series System comes equipped with our new High Flow Adjustable Regulator which can provide excellent pressure regulation up to 600 gallons per hour!
The Competition Series utilizes our Extreme Water Separator that removes over 99 percent of the water that can be found in diesel fuel (3rd party laboratory tested) and filters out damaging particulates down to 2 microns. This is a universal System and does not come with fuel lines, wiring, or fittings.
Electrical Requirements: Each motor will need a 10 amp fuse and we recommend 10 gauge wiring to each motor. Each electric motor can draw up to 10 amps max.
Fuel Line Requirements: A single -12 suction line is recommended while a -8 or -10 engine feed and FASS return line is sufficient.
Competition Series 330G Information:
- Supplied with Our Universal Mounting Bracket.
- Pressure Adjustable from 0-30 PSI.
- -10 AN Inlet, Outlet, and Pressure Regulator Ports.
- Removes Water, Air and Debris from Diesel Fuel.
- 2 Micron Filtration Rating.
- 1/8 NPT Pressure Gauge Port.
- Easier to prime than a mechanical gear System.
30 PSI Maximum Pressure.
Competition Series 330G Flow Rates:
- 336 Gallons Per Hour at Free Flow (0 PSI).
- 324 Gallons Per Hour at 10 PSI.
- 312 Gallons Per Hour at 15 PSI.
- 306 Gallons Per Hour at 20 PSI.
- 300 Gallons Per Hour at 25 PSI
- 294 Gallons Per Hour at 30 PSI.
Two WH-1006-3R can be purchased to power the FASS Competition Series motors if you do not wish to build a custom wire harness.
The FASS COMP330G Fuel Systems Competition Series is engineered for high-performance diesel applications, delivering an impressive 330 gallons per hour (GPH) with a maximum pressure of 30 PSI. Designed for enthusiasts and professional users alike, this system ensures a robust fuel supply for your demanding needs.At the heart of the FASS Competition Series lies a cutting-edge High Flow Adjustable Regulator, offering precise pressure regulation and adaptability to various setups. The system boasts an Extreme Water Separator, which has been rigorously tested to remove over 99% of water, safeguarding your engine against damage. Plus, with a filtration capability that catches particles down to 2 microns, your diesel fuel will be clean and free from harmful contaminants.
Customization is straightforward with the Competition Series. It features a universal mounting bracket and -10 AN inlet, outlet, and pressure regulator ports, making it easy to integrate into your existing system. Notably, the system is engineered for simplicity, as it is easier to prime than traditional mechanical gear systems, ensuring a hassle-free installation process.
Electrical requirements include a 10 amp fuse and a recommendation for 10 gauge wiring, accommodating up to 10 amps per electric motor. Fuel line specifications suggest a single -12 suction line paired with -8 or -10 lines for engine feed and return, providing flexibility in setup configurations.
Flow rates are impressive, varying from 336 GPH at no pressure to 294 GPH at maximum pressure, ensuring that no matter your driving conditions, you’ll have the required fuel supply to perform at your best. Elevate your diesel performance with the FASS COMP330G Competition Series fuel system, where reliability meets high-octane demand.
