BDS SUSPENSION BDS725H 6 INCH LIFT KIT GMC SIERRA 1500 14-18 4WD MAGNERIDE EQUIPPED CAST STEEL CONTROL ARM

Take your 2014-2018 GMC Sierra 1500 to new heights with a BDS 6-inch lift kit. Works only on Magneride equipped trucks. Designed to improve stance, performance, and capability, this kit includes everything necessary to set your truck up right with clearance for up to 35 inch Tires

This kit takes advantage of BDS's tried and true high-clearance design for improved ground clearance, strength, and offroad protection while correcting suspension and steering geometry for great on-road handling characteristics.

Up front, the kit utilizes a top mounted strut spacer, high-arched 1/4-inch thick steel crossmembers along with a multipiece differential relocation brackets and heavy duty skid plates built for offroad protection.

Steering geometry is corrected at the new taller ride height with CNC-machined ductile iron steering knuckles. These combined with the provided sway bar drops, bump stop extensions, brake line brackets, CV spacers, supplied hardware and more provide a comprehensive front suspension lift ready for whatever you throw at it.

In the rear BDS offers new Pro-Ride coil springs for on-road ride quality as well as serious off road performance, anti-sway bar links, track bar relocation system, and adjustable upper control arms allowing you to properly adjust pinion angle. The rear sensors are relocated using the supplied brackets along with rear shock extensions to retain the factory electronic dampers.

High Clearance Crossmembers

BDS maximizes ground clearance with their heavy duty 1/4-inch thick laser cut perfect fit crossmembers. Paired with a front skid plate system that bolts together to create a rigid subframe while adding extra protection.

Heavy Duty Steering Knuckles

BDS corrects steering geometry at the new taller ride height using a pair of high-strength, CNC machined ductile cast iron steering knuckle design to work with factory tie rod ends to maintain steering angles for proper function and ESC compatibility.

• Front Lift Method: Cross-Member
• Rear Lift Method: Block
• Shocks Included: No
• Front Lift Height: 6 inch
• Rear Lift Height: 5 inch

Important: GM is producing several knuckle/control arm configurations in 2014-2017 models trucks. Cast Steel control arm equipped models will require the inchCast Steel Control Arm inch kit. Stamped Steel and Aluminum control arm equipped models will require the Aluminum Control Arm kit. Be sure to verify which factory control arms your truck has before ordering by referencing our help images when customizing your kit.

1. Requires frame bracket modification
2. Requires differential modification to clear electric power steering
3. Vehicles came from the factory with several knuckle/control arm configurations requiring specific kit selections.
4. Factory 17 inch and 18 inch wheels cannot be reinstalled due to tie rod end interference.

• Includes shock relocation brackets to maintain factory Magneride shocks
• High clearance crossmember design maximizes ground clearance
• Robust steering knuckles maintain ESC system compliance
• High-strength replacement upper control arms provide durability and serviceability
• HD skid plate system improved offroad protection
• Multipoint differential relocation brackets to secure the front axle and improve CV angles
• Factory Protection Plus drivetrain warranty included

Factory Control Arm Type Cast Steel Control Arm

Important: GM is producing several knuckle/control arm configurations in 2014-2018 models trucks. Cast Steel control arm equipped models will require the inchCast Steel Control Arm inch kit. Stamped Steel and Aluminum control arm equipped models will require the Aluminum Control Arm kit. Be sure to verify which factory control arms your truck has before ordering

Tire Size: 34 x 12.5 Tire Size 2: 35 x 12.5 Wheel Diameter: 18 x 9 Wheel Diameter 2: 20 x 9 Back Spacing: 5/5.75

Kit Components:

• Includes one BDS011505, 2014 Chevy 1500 5 inch Rear Block Kit, UPC Code 658848611898
• Includes one BDS021660, 14-18 GM 1500 - 15-19 GM SUV Knuckle Box - Cast, UPC Code 658848615018
• Includes one BDS021662, 14-18 GM 1500 - 15-19 GM SUV 1500 6 inch Frt Box Kit (1of2), UPC Code 658848615032
• Includes one BDS021663, 14-18 GM 1500 15-19 GM SUV 6 inch Frt Box Kit (2of2), UPC Code 658848615049
• Includes one BDS121655, 2014-up GMC Denali Magneride Box Kit, UPC Code 658848619252

Elevate your GMC Sierra 1500 from 2014 to 2018 with the BDS725H 6-inch Lift Kit, specifically engineered for trucks equipped with Magneride. This comprehensive lift kit enhances not just the height but the overall performance and capability of your vehicle, making way for tires up to 35 inches, while improving stance and ground clearance.

The BDS725H takes advantage of a robust high-clearance design, offering exceptional protection and support for off-road adventures. The installation features a top-mounted strut spacer, high-arched 1/4-inch thick steel crossmembers, and durable multipiece differential relocation brackets that promise optimal suspension and steering geometry. Your truck will maintain great on-road handling, mitigating steering issues thanks to CNC-machined ductile iron steering knuckles that ensure proper tie rod function and ESC compatibility under the new ride height.

In the rear, the kit comes complete with Pro-Ride coil springs designed to deliver remarkable on-road comfort alongside top-tier off-road capabilities. The adjustable upper control arms and track bar relocation system allow for precise adjustment of the pinion angle, while brake line brackets and rear shock extensions ensure seamless integration of factory electronic dampers.

The expert engineering behind the BDS725H kit emphasizes strength: its laser-cut heavy-duty crossmembers and a well-structured skid plate system provide enhanced protective measures for any off-road endeavors. Additionally, the comprehensive details ensure all setups, from steering to suspension, are optimized for ensuring lifted performance.

Installation is made simpler with the inclusion of shock relocation brackets, allowing you to retain factory Magneride shocks. For peace of mind, this kit comes backed with a Factory Protection Plus drivetrain warranty. Transform your GMC Sierra's look and off-road prowess with the BDS SUSPENSION BDS725H 6 INCH LIFT KIT.
