BDS SUSPENSION BDS320FS 2 INCH LEVELING KIT FORD F250/F350 SUPER DUTY 99-04 4WD RADIUS FRONT U BOLT FOX 2.0 PERFORMANCE SHOCKS

Improve the ride and level out your 1999-2004 Ford F250 and F350 Super Duty truck with this 2-inch leveling kit from BDS Suspension. Designed to improve stance, performance, and capability, this kit includes everything necessary to set your truck up right with clearance for up to 33 inch Tires.

Up front the lift kit includes Glide-Ride leaf springs, track bar bracket for steering correction, extended sway bar links and custom-tuned nitrogen charged shocks. In the rear this kit utilizes a matching set of NX2 Nitro or FOX Performance shocks.

Glide-Ride Leaf Springs

Built to outperform, BDS engineered the Glide-Ride leaf springs into a multi-leaf progressive spring rate design that provides a smooth ride with any load. This is accomplished with an exclusive triple-stage leaf spring design. Upgrading to BDS Glide-Ride leaf springs will provide flexibility throughout the suspension cycle.

• Front Lift Method: Leaf Spring
• Rear Lift Method: Stock
• Shocks Included: Yes
• Front Lift Height: 2 Inch
• Rear Lift Height: 0 Inch

1. These truck were manufactured with two different style front u-bolts. You will need to know if your front leaf spring u-bolts are square or are half way between round and square with a gentle radius around the OE cast u-bolt plate before ordering.
2. Will not fit vehicles manufactured before 3/1/99.
3. The stock Super Duty came with a rear 2 Inch, 3 Inch, or 4 Inch rear block. You may need to change the block and/or u-bolts in order to level the truck.
4. 003202, #003402, #003602, #003609, #003802, and #003809 come with OE rubber bushings installed
5. Confirm build date, front u-bolt type and rear leaf pack overload position before ordering

• Easy, 100 percent Bolt-on installation
• Glideride leaf springs to provide full lift height and increased capacity
• Track bar relocation bracket maintains proper steering angles for improved handling
• Standard NX2 Nitro shocks with vehicle-specific valving for better control
• Upgrade to FOX 2.0 Performance Series shocks for maximum performance on and off-road

Front U-Bolt Type - Square

This vehicle was manufactured with either square front U-Bolts or radiused front U-bolts. Typically, 1999-2000 are square and 2001-2004 are radiused, but that is not always the case.

The radiused U-bolts aren't square or round, but rather have a gentle radius that matches a cast factory upper U-bolt plate on top of the factory spring. Vehicles manufactured prior to 2-28-99 require yet another different box kit due to a change in the factory track bar.

FOX 2.0 Performance Series

• 2-inch Impact extruded aluminum body
• Internal floating piston (Internal Floating Piston) monotube design
• CNC machined 6061-T6 aluminum mounting ends
• Massive 5/8-inch hard chrome plated heat-treated alloy steel shaft
• Race-developed high-flow piston design
• Application-specific valving to maximize performance
• Long-lasting clear anodized finish

Kit Components:

• Includes two BDS003202, Ford F250/350 2 Inch Front Spring, UPC Code 658848611317
• Includes one BDS013253, Ford F250/350 2.5 InchFront Box Kit, UPC Code 658848613205
• Includes two FOX98224650, Fox 2.0 Shock 26.85 x 16.75 x 2- EB1/EB1
• Includes two FOX98224660, Fox 2.0 Shock 30.05 x 18.45 x 2- EB1/EB1

Enhance your driving experience with the BDS Suspension BDS320FS 2 Inch Leveling Kit, specifically designed for the 1999-2004 Ford F250 and F350 Super Duty 4WD. This comprehensive leveling kit not only improves the stance of your truck but also elevates performance and capability, allowing for the fit of larger 33-inch tires.

The package includes premium Glide-Ride leaf springs that feature a progressive spring rate design, promoting a smoother ride regardless of load. Engineered with an exclusive triple-stage design, these springs facilitate greater flexibility throughout the suspension cycle. The kit further elevates your vehicle with a 2-inch front lift while maintaining the stock height in the rear.

Included in this kit are essential components such as a track bar bracket that ensures proper steering alignment, extended sway bar links, and a choice of standard NX2 Nitro shocks or upgraded FOX 2.0 Performance shocks, tailored for enhanced control and off-road performance. The shocks are constructed with top-quality materials, including a heavy-duty aluminum body and high-flow piston design, making them perfect for both on-road comfort and off-road adventures.

Installation is straightforward with a completely bolt-on design, minimizing the need for modifications. However, it’s essential to verify specific details of your vehicle, including front U-bolt type and build date, to ensure compatibility.

Consider the BDS320FS leveling kit an investment in your Ford Super Duty's ride quality and functionality. Elevate your truck's look and performance today, and conquer any terrain confidently with this carefully crafted suspension upgrade.
