BDS SUSPENSION
BDS SUSPENSION BDS1679H 4 INCH LIFT KIT W/ 4-LINK RAM 3500 19-23 4WD GAS WITH FACTORY REAR OVERLOAD LEAF NX2 NITRO
- SKU:
- BDS1679H
- MPN:
- BDS1679H
- Shipping:
- Calculated at Checkout
Description
Raise your RAM 3500 gas powered truck to the next heights with this 4-inch lift kit with 4-Link conversion from BDS Suspension. Designed to improve stance, performance, and capability, this kit includes everything necessary to set your truck up right with clearance for up to 35 tires.
Up front the lift kit includes gas-specific Pro-Ride coil springs, 4-Link control arms and conversion brackets, forged drop pitman arm and track bar bracket for steering correction, sway bar relocation, brake line brackets and precision tuned NX2 or FOX 2.0 nitrogen charged shocks.
At this height, the transfer case needs to be indexed to allow use of the factory front driveshaft so an indexing ring and new transmission crossmember are supplied. In the rear this kit utilizes a high-strength steel lift block, longer u-bolts and a matching set of NX2 Nitro or FOX 2.0 Performance shocks.
Rear Lift Option With Factory Rear Overload Leaf - NX2 Nitro Shocks
Select rear box kit based on whether or not your RAM has factory Rear Overload Leaf.
- Indexing Ring
- 6 Bolt Indexing Ring
- Kits come standard with 6-Bolt indexing ring kit.
Kit Components:
- Includes one BDS012216, 2019-2024 Ram 3500 2 inch Rear Box 4 3/8 inch U-bolt w/ overload, UPC Code 658848612123
- Includes one BDS012433, 2019-2024 Ram 2500 / 2019-2024 Ram 3500 4-Link Box Kit 1of2, UPC Code 658848612437
- Includes one BDS012434, 2019-2024 Ram 2500 / 2019-2024 Ram 3500 4-Link Box Kit - 2 of 2, UPC Code 658848612444
- Includes one BDS032302, 2013-2024 Ram 3500 / 2014-2024 2500 Ram Coils 3 inch Diesel - 4 inch Gas, UPC Code 658848616343
- Includes one BDS122626, 2019-2024 Ram 2500 / 2019-2024 Ram 3500 T-Case Index - 6 Bolt - Gas, UPC Code 658848619788
- Includes two BDS85700, Shock- 25.20 x 15.20 x 2-3/8 - S50/EB2, UPC Code 711745609495
- Includes two BDS85759, Shock- 29.80 x 17.60 x 2-3/8 - EB1/EB1, UPC Code 711745609686
The kit is meticulously crafted to improve your truck’s stance and driving dynamics. It includes gas-specific Pro-Ride coil springs that ensure the optimal ride quality and support. The innovative 4-Link control arms and conversion brackets work in tandem with a forged drop pitman arm and steering correction track bar bracket to maintain precise steering control. To further enhance stability, the kit features a sway bar relocation and brake line brackets, paired with NX2 or FOX 2.0 nitrogen-charged shocks for superior dampening performance.
Addressing the needs of your transfer case, the kit includes an indexing ring and a robust transmission crossmember, ensuring a secure fit for the factory front driveshaft after the lift. In the rear, a high-strength steel lift block, longer u-bolts, and a matching set of NX2 Nitro or FOX 2.0 Performance shocks promise reliable support and responsiveness.
With options tailored for vehicles equipped with a factory rear overload leaf, this kit caters to a variety of configurations. The comprehensive hardware package includes essential components such as the rear box kit for enhanced strength and performance, making installation seamless.
With the BDS Suspension BDS1679H 4-Inch Lift Kit, elevate not just the height of your RAM 3500, but also your adventures. This kit combines rugged durability with advanced engineering, ensuring you tackle any terrain with confidence.
