BDS SUSPENSION BDS1510FPE 2.5 INCH LIFT KIT FOX 2.5 PERFORMANCE ELITE COIL-OVER CONVERSION FORD F250/F350 SUPER DUTY 11-16 4WD DIESEL 4 INCH BLOCK KIT FOX 2.5 PERFORMANCE ELITE SHOCKS

Improve the ride, up the ante, and level out your 2011-2016 Ford F250 and F350 Super Duty diesel powered truck with this 2.5-inch radius arm lift kit and FOX Performance Elite coil-over conversion from BDS Suspension. Designed to improve stance, performance, and capability, this kit includes everything necessary to set your truck up right with clearance for up to 35 inch tires.

Up front the lift kit includes diesel-specific FOX 2.5 coil-over shocks, high strength 1-3/8 inch solid steel track bar for steering correction, brake line brackets and precision tuned nitrogen charged shocks.

In the rear this kit utilizes a high-strength fabricated lift block, longer u-bolts and a matching set of NX2 Nitro or FOX Performance shocks.

FOX Performance Elite Coil-Over
FOX 2.5 Performance Elite shocks offer next level performance for on-road comfort and off-road comfort capability. Tuned and ready to install right out of the box, these bolt-on 2.5-inch diameter shocks are built for abuse and packed with race-proven technology.

They include a remote reservoir for additional fluid capacity to keep your shocks running cool so you can push the limits in the rough terrain.

The DSC adjuster adds remarkable versatility and precise tuning with a simple twist of either two adjuster knobs, offering 10 separate low-speed and 12 high-speed compression levels, with a black anodized aluminum reservoir to increase cooling efficiency.

HD Adjustable Track Bar
Maintain proper handling and steering geometry with the BDS high strength adjustable track bar that allows you to recenter the front axle at a variety of lift heights. Built from 1-3/8 inch solid steel stock, the track bar comes pre-assembled with bushings and is ready to bolt into the factory mounting points.

Features & Benefits

FOX 2.5 Coil-Over mounts in factory coil bucket location
Adds additional secondary FOX 2.0 shock for max performance
Eibach coil springs ride smooth through the roughest terrain
Adjustable solid steel track bar designed to recenter the front axle
Fabricated steel blocks provide level stance from front to rear
FOX shocks are fully serviceable and resistant to corrosion and harsh environments.
Recommended Tires & Wheels

• (Trimming may be required)
• 35 x 12.5 with 17 x 9 and 5 in. Backspace
• 35 x 12.5 with 18 x 9 and 5 in. Backspace
• 35 x 12.5 with 20 x 9 and 5 in. Backspace

Rear Lift Option

• 4 Inch Block Kit
• Front Lift Method: Coil-Over
• Rear Lift Method: Block
• Shocks Included: Yes
• Front Lift Height: 2.5 inch
• Rear Lift Height: 1 inch

Kit Components:

• Includes one BDS013254, 2005-15 F250 2.5 InchFront Box Kit, UPC Code 658848613212
• Includes one BDS013408, 2011-15 F250 4 Inch Rear Block Kit, UPC Code 658848613403
• Includes one BDS123212, 2005-2016 Ford F250/F350 Super Duty Coilover Mount Kit (2 inch-8 inch), UPC Code 711745604063
• Includes one FOX88406426, Kit: BDS 2005-On Ford SD Front Coilover, 2.5 Truck Fox Performance Elite Series, R/R 2.5 inch Lift, Dual Speed Compression Adjust
• Includes two FOX98224710, Fox 2.0 Shock 23.27 x 14.65 x 2- S50/EB1
• Includes two FOX98224760, Fox 2.0 Shock 33.85 x 20.75 x 2- EB1/EB1

Transform your 2011-2016 Ford F250 and F350 Super Duty diesel truck with the BDS SUSPENSION BDS1510FPE 2.5 Inch Lift Kit featuring FOX 2.5 Performance Elite coil-over conversion. Designed to elevate not just the stance but also the overall performance and capability, this comprehensive lift kit allows for the installation of tires up to 35 inches in size, enhancing both off-road adventures and on-road driving dynamics.

This thoughtfully engineered kit showcases diesel-specific FOX 2.5 coil-over shocks at the front, ensuring superior handling and responsiveness. The high-strength 1-3/8 inch solid steel track bar promotes optimal steering correction while brake line brackets and precision-tuned nitrogen-charged shocks guarantee smooth operation.

The rear of the truck gets a robust upgrade through a fabricated lift block, longer u-bolts, and a complimentary set of NX2 Nitro or FOX Performance shocks. Equipped with a remote reservoir, the FOX 2.5 Performance Elite shocks maintain optimal operating temperatures, allowing for prolonged performance under demanding conditions. The innovative DSC adjuster empowers you with ten low-speed and twelve high-speed compression settings, enhancing versatility to tackle diverse terrains effortlessly.

With the included high-strength adjustable track bar, you can maintain precise steering and handling by recentering the front axle across different lift heights. This kit not only elevates your truck's profile but also assures durability with features like fully serviceable FOX shocks designed to withstand corrosion and harsh environments.

Experience the perfect blend of style and functionality with the BDS SUSPENSION 2.5 Inch Lift Kit, a pioneering solution for your F250/F350 that promises unmatched performance and a striking presence on and off the road.
