BDS SUSPENSION BDS1406H 4.5 INCH LIFT KIT JEEP WRANGLER JK 12-18 4-DOOR FIXED SWAY BAR LINK NX2 NITRO SHOCKS

Take your 2012-2018 Jeep Wrangler JK 4 Door to the next level and improve the ride with this 4.5-inch lift kit from BDS Suspension. Designed to improve stance this kit includes everything necessary to set your truck up right with clearance for up to 37 inch Tires.

Up front the lift kit includes 4 inch Pro-Ride coil springs capable of full coil bind and 3 inch bump stop extensions to control the compression travel, but increase wheel travel. Also included are brake line brackets, sway bar links, and front track bar relocation bracket and pitman arm to improve the steering and handling geometry. The front suspension in this 4-inch lift kit is finished off with fixed length lower control arms with OE grade rubber bushings that re-position the front axle for proper alignment.

In the rear the kit utilizes Pro-Ride coil springs, sway bar drop brackets, and a rear frame mounted track bar relocation bracket to correct axle shift. For proper rear axle position and pinion angle this kit includes fixed length rear lower control arms and adjustable rear upper arms. Round out this 4 inch lift kit with your choice of specially tuned NX2 nitro series gas shocks or FOX 2.0 Internal Floating Piston performance series gas shocks to offer improved damper performance.

Pro-Ride Coil Springs

A pair of full-length, gas-specific, progressive rate Pro-Ride coil springs are supplied to provide the correct lift height and smooth, predictable ride across various terrains. Manufactured from high tensile steel, our direct OE replacement coil springs are engineered with properly sized wire diameter. This results in maximum reliability without premature coil bind.

Steering Correction

To optimize steering geometry once lifted, a forged drop pitman arm is used to minimize the steering angle and pair it with a heavy duty track bar drop bracket to keep them in phase through suspension travel while recentering the front axle.

• Front Lift Method: Coil Spring
• Rear Lift Method: Coil Springs
• Shocks Included: Yes
• Front Lift Height: 4.5 inch
• Rear Lift Height: 4 inch

1. Will not fit 2wd models.
2. The fixed front and rear lower control arms can be upgraded to the adjustable flex end arms listed in the accessories.
3. The front driveshaft is maxed out at full droop and on certain models the driveshaft boot can contact the transmission pan.
4. Exhaust modification may be required.
5. This kit is FMVSS No.126 Compliant

• ProRide coil springs offer improved ride quality and more articulation
• Sway bar quicker disconnects and extended rear link for improved offroad flex
• New control arms to properly control the front and rear axle positions
• Rear track bar bracket repositions rear axle under vehicle
• Choice of NX2 gas or FOX 2.0 Internal Floating Piston performance series shocks for improved damping
• Allows clearance for 37 inch Tires

Shock Option NX2 Nitro Series

• Nitrogen-charged
• Twin-tube design
• 10-stage velocity-sensitive valving
• Dual-welded ends for increased strength
• 1-3/8-inch high-flow piston
• Self-lubricating seals
• Silver powder coat finish

Fixed Links

• Required for use on Rubicon models with electronic disconnect.
• Improves handling with proper sway bar operating angle
• Heavy-duty steel construction with zinc finish
• Polyurethane hourglass bushings for long life and quiet operation

Kit Components:

• Includes one BDS014456, Jeep Wrangler JK Rubicon 4 Inch Box Kit, UPC Code 658848614189
• Includes one BDS034411, 2007-2018 Jeep Wrangler (JK) 2 Door /5.5in 4 Door/4.5in Front Coil Kit, UPC Code 658848616855
• Includes one BDS034419, 2007-2018 Jeep Wrangler (JK) 2 Door /5in 4 Door/4 Inch Rear Coil Kit, UPC Code 658848616862
• Includes one BDS124314, 2012-18 Jeep Wrangler JK Exhaust Extension Kit, UPC Code 711745605015
• Includes one BDS124331, 2007-2018 Jeep Wrangler (JK) Front Fixed LCA Kit, UPC Code 711745605114
• Includes one BDS124339, Jeep Wrangler JK Rear Fixed LCA Kit, UPC Code 711745605169
• Includes two BDS85700, Shock- 25.20 x 15.20 x 2-3/8 - S50/EB2, UPC Code 711745609495
• Includes two BDS85959, Shock- 28.00 x 16.50 x 2-3/8 - BP18/EB1, UPC Code 711745610101

Elevate your 2012-2018 Jeep Wrangler JK 4-Door with the BDS SUSPENSION BDS1406H 4.5-Inch Lift Kit and experience unparalleled off-road performance and enhanced ride quality. This comprehensive lift kit is expertly engineered to provide a remarkable 4.5-inch lift, offering the clearance needed for up to 37-inch tires, resulting in a commanding stance that turns heads both on and off the trails.

The BDS lift kit features Pro-Ride coil springs at the front, designed for maximum articulation and performance, paired with 3-inch bump stop extensions to manage compression travel effectively. Complete with brake line brackets, sway bar links, and a front track bar relocation bracket, the kit ensures excellent steering and handling geometry. Finished with fixed-length lower control arms that incorporate OE-grade rubber bushings, this kit optimally repositions the front axle for precise alignment in varying terrains.

In the rear, Pro-Ride coil springs and sway bar drop brackets work in tandem with a rear frame-mounted track bar relocation bracket to correct axle shift, while adjustable upper arms allow for fine-tuning of pinion angle and rear axle positioning. Complement the lift with your choice between specially tuned NX2 Nitro Series shocks or FOX 2.0 Internal Floating Piston performance series gas shocks, both designed for superior damping and improved handling.

This lift kit not only enhances your Jeep's capability on rugged paths but also provides the safety of FMVSS No.126 compliance. Engineered with high tensile steel and finished with durable protective coatings, each component promises long-lasting performance. Perfect for adventurous drivers seeking a blend of style, stability, and off-road prowess, the BDS1406H Lift Kit is the ultimate upgrade for exceptional journeys ahead.
